Krome- 20″x 7″ Side Spray Glass Rinser Drip Tray – Brushed Stainless – With Drain
DESCRIPTION :
We are the prominent manufacturer and supplier of high quality Stainless Steel Drip tray.The offered product is available in assorted specifications, which fit the assorted requirements of the customers. This product is perfectly designed and manufactured employing the best quality raw material in order to meet the set industry parameters. Besides, customers can avail this product from us at market leading rates.
FEATURES :
It Is Used To Rinse Glass.
It Has Brushed Finish.
COMPONENT INCLUDES:
C958 - Standard Drain Assembly-3-1/2″ .
C029- 1/2″ BSP Connector With 3/8″ OD X 5 Feet Hose – PP Pipe Assembly.
INSTALLATION INSTRUCTIONS:-
Rinser Water Inlet Installation Instructions
Always check with local plumbing codes before Installation
For Use with Regular or cold water supply only, Hot water is not recommended to use with rinser
Install in-line water regulator set at 15 PSI from the public water supply, no more than 15 Psi
Install an in-line one-way check valve on water supply this will prevent pressure drop which can cause leakage
Install in-line shut-off for the rinser system from the water supply, this must be turned off if not in use for extended periods such as off days or night time!
SPECIFICATIONS
VALUE
Material
Stainless Steel 304
Finish
Brushed Stainless
Type
With Drain
Length
20"
Width
7"
Approval
NSF Certified (Rinser Only)
